Intercepting Docker API Requests via UNIX Socket with Burp Suite
Docker is now a household name in container technology, and for good reason. The Docker CLI makes managing containers and everything related to them incredibly simple and efficient, making it a go-to tool in my workflow.
Docker CLI uses REST API to connect to Docker Daemon (dockerd), which by default listens for requests on the UNIX socket, ideally located at /var/run/docker.sock, to only allow local connections by the root user. We do have another option to expose a TCP port and proxy curl command through it. We will emulate the Docker CLI requests using cURL.
We need to have a bridge between the Unix socket and a local TCP port, which will act as a gate to the unix socket.
One of the best tools to create this relay will be socat. According to the manual -
Socat is a command line based utility that establishes two bidirectional byte streams and transfers data between them. We will use socat to create a bridge between a random TCP port and the unix socket.
Installation
It is easily available on brew and can be easily installed using the command - brew install socat
Pre-requisites
Before executing, we need to setup Burp Proxy. No special configuration changes are needed and simple following steps from this documentation should work - https://portswigger.net/burp/documentation/desktop/external-browser-config.
Burp Suite for my system is configured on the port 8080 - HTTP requests sent to that port, will be available in Burp. Simply putting burp intercept to off and seeing the requests in Proxy history will work.
After sucessfully setting up Burp, to get the request to docker Daemon and response back, we need to have the Docker running in our system. Easiest way to verify if daemon is running or not by simpy executing the docker ps command. If you see a connection error, that indicates thet daemon is not running and needs to be initialized.
Process
socat seems to be a pretty powerful tool and just listing the help command, gives list of available flags/commands, extending more than a page.
rarya@rarya-MAC2 ~ % socat -h
socat by Gerhard Rieger and contributors - see www.dest-unreach.org
Usage:
socat [options] <bi-address> <bi-address>
options (general command line options):
-V print version and feature information to stdout, and exit
-h|-? print a help text describing command line options and addresses
-hh like -h, plus a list of all common address option names
-hhh like -hh, plus a list of all available address option names
-d[ddd] increase verbosity (use up to 4 times; 2 are recommended)
-d0|1|2|3|4 set verbosity level (0: Errors; 4 all including Debug)
-D analyze file descriptors before loop
--experimental enable experimental features
--statistics output transfer statistics on exit
-ly[facility] log to syslog, using facility (default is daemon)
-lf<logfile> log to file
-ls log to stderr (default if no other log)
-lm[facility] mixed log mode (stderr during initialization, then syslog)
-lp<progname> set the program name used for logging and vars
-lu use microseconds for logging timestamps
-lh add hostname to log messages
-v verbose text dump of data traffic
-x verbose hexadecimal dump of data traffic
-r <file> raw dump of data flowing from left to right
-R <file> raw dump of data flowing from right to left
-b<size_t> set data buffer size (8192)
-s sloppy (continue on error)
-S<sigmask> log these signals, override default
-t<timeout> wait seconds before closing second channel
-T<timeout> total inactivity timeout in seconds
-u unidirectional mode (left to right)
-U unidirectional mode (right to left)
-g do not check option groups
-L <lockfile> try to obtain lock, or fail
-W <lockfile> try to obtain lock, or wait
-0 do not prefer an IP version
-4 prefer IPv4 if version is not explicitly specified
To expose the Unix socket over TCP we will use the command:
socat TCP-LISTEN:12345,fork UNIX-CONNECT:/var/run/docker.sock
Note: Observe the fork keyword in the command. This will ensure that socat do not terminate after we execute a cURL request, and stays ALIVE.
-
Imagine the TCP port 12345 as the gateway to the docker socket. Anything send to this port will be forwarded to the socket, where docker daemon is listening.
-
UNIX-CONNECT - is the location of the docker socket. By default it is located at /var/run/docker.sock and but might vary based on the system. Ref- https://docs.docker.com/reference/cli/dockerd/
Executing the command, would not show any output in the console.
rarya@rarya-MAC2 ~ % socat TCP-LISTEN:12345,fork UNIX-CONNECT:/var/run/docker.sock
In another terminal, we will send the cURL request. To correctly formulate the request we need to keep two things in mind:
-
The request should be proxied to port where burp is listening i.e. localhost:8080
-
The cURL requests should be made to the exposed TCP port from the
socatcommand - 12345
Working on the cURL request it would simply narrow down to -
curl -x http://localhost:8080 http://localhost:12345/v1.47/containers/json
Observation:
-xparameter to proxy request to the port 8080- Request is sent to the endpoint
/v1.47/containers/json- which retrieves details about running containers.
Docker API details can be found at - https://docs.docker.com/reference/api/engine/version/v1.47/
Burp
Observe the response in the terminal after sending thr cURL request:
rarya@rarya-MAC2 ~ % curl -x http://localhost:8080 http://localhost:12345/v1.47/containers/json
[
{
"Id": "42322aadee1b49159303cb9a7dbd8b0ae947b0836acbbcdd1200e883e69186d9",
"Names": [
"/kind_dhawan"
],
"Image": "ubuntu",
"ImageID": "sha256:1a799365aa63eed3c0ebb1c01aa5fd9d90320c46fe52938b03fb007d530d8b02",
"Command": "sh",
"Created": 1727660843,
"Ports": [],
"Labels": {
"org.opencontainers.image.ref.name": "ubuntu",
"org.opencontainers.image.version": "24.04"
},
"State": "running",
"Status": "Up 3 minutes",
"HostConfig": {
"NetworkMode": "bridge"
},
"NetworkSettings": {
"Networks": {
"bridge": {
"IPAMConfig": null,
"Links": null,
"Aliases": null,
"MacAddress": "02:42:ac:11:00:02",
"DriverOpts": null,
"NetworkID": "20d5499484aa15256478966b748376a1ac750b90c0691a7e8c228c7fa5c4ad6a",
"EndpointID": "024578205af5a3a1fc8555c1c4bcc2623993ba946e532acc7765a14d55523801",
"Gateway": "172.17.0.1",
"IPAddress": "172.17.0.2",
"IPPrefixLen": 16,
"IPv6Gateway": "",
"GlobalIPv6Address": "",
"GlobalIPv6PrefixLen": 0,
"DNSNames": null
}
}
},
"Mounts": []
}
]
We get the details of the docker containers running on the system. Now check Burp Proxy history for any requests. You should see a GET request made to the address - localhost:12345 like the below screenshot:
Finally, we got the request in Burp. To have fun with docker daemon calls, send the request to Burp Repeater, and start playing with different methods, and paramteres. By leveraging the API documentaion, you can easily upate the request in Burp and forward it.
This request is querying the images in the local docker registry.
Docker CLI commands in the background send similar API calls to the docker daemon through the Unix socket. Intercepting these requests through Burp gives a clear understanding of how things work, and provides a nice steady interface for security testing.
